QGeneralisedAxisymAdvectionDiffusionElement elements are linear/quadrilateral/brick-shaped Advection Diffusion elements with isoparametric interpolation for the function. More...

#include <gen_axisym_advection_diffusion_elements.h>

Inheritance diagram for QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >:

Public Member Functions
	QGeneralisedAxisymAdvectionDiffusionElement ()
	Constructor: Call constructors for QElement and Advection Diffusion equations. More...

	QGeneralisedAxisymAdvectionDiffusionElement (const QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D > &dummy)
	Broken copy constructor. More...

unsigned	required_nvalue (const unsigned &n) const
	Broken assignment operator. More...

void	output (std::ostream &outfile)
	Output function: r,z,u. More...

void	output (std::ostream &outfile, const unsigned &n_plot)
	Output function: r,z,u at n_plot^2 plot points. More...

void	output (FILE *file_pt)
	C-style output function: r,z,u. More...

void	output (FILE *file_pt, const unsigned &n_plot)
	C-style output function: r,z,u at n_plot^2 plot points. More...

void	output_fct (std::ostream &outfile, const unsigned &n_plot, FiniteElement::SteadyExactSolutionFctPt exact_soln_pt)
	Output function for an exact solution: r,z,u_exact at n_plot^2 plot points. More...

void	output_fct (std::ostream &outfile, const unsigned &n_plot, const double &time, FiniteElement::UnsteadyExactSolutionFctPt exact_soln_pt)
	Output function for a time-dependent exact solution. r,z,u_exact at n_plot^2 plot points (Calls the steady version) More...

Protected Member Functions
double	dshape_and_dtest_eulerian_cons_axisym_adv_diff (const Vector< double > &s, Shape &psi, DShape &dpsidx, Shape &test, DShape &dtestdx) const
	Shape, test functions & derivs. w.r.t. to global coords. Return Jacobian. More...

double	dshape_and_dtest_eulerian_at_knot_cons_axisym_adv_diff (const unsigned &ipt, Shape &psi, DShape &dpsidx, Shape &test, DShape &dtestdx) const
	Shape, test functions & derivs. w.r.t. to global coords. at integration point ipt. Return Jacobian. More...

Static Private Attributes
static const unsigned	Initial_Nvalue
	Static array of ints to hold number of variables at nodes: Initial_Nvalue[n]. More...

Detailed Description

template<unsigned NNODE_1D>
class QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >

QGeneralisedAxisymAdvectionDiffusionElement elements are linear/quadrilateral/brick-shaped Advection Diffusion elements with isoparametric interpolation for the function.

Definition at line 607 of file gen_axisym_advection_diffusion_elements.h.

Constructor & Destructor Documentation

◆ QGeneralisedAxisymAdvectionDiffusionElement() [1/2]

template<unsigned NNODE_1D>

QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::QGeneralisedAxisymAdvectionDiffusionElement ( )

inline

Constructor: Call constructors for QElement and Advection Diffusion equations.

Definition at line 623 of file gen_axisym_advection_diffusion_elements.h.

◆ QGeneralisedAxisymAdvectionDiffusionElement() [2/2]

template<unsigned NNODE_1D>

QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::QGeneralisedAxisymAdvectionDiffusionElement ( const QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D > & dummy )

inline

Broken copy constructor.

Definition at line 628 of file gen_axisym_advection_diffusion_elements.h.

References oomph::BrokenCopy::broken_copy().

Member Function Documentation

◆ dshape_and_dtest_eulerian_at_knot_cons_axisym_adv_diff()

template<unsigned NNODE_1D>

double QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::dshape_and_dtest_eulerian_at_knot_cons_axisym_adv_diff	(	const unsigned &	ipt,
		Shape &	psi,
		DShape &	dpsidx,
		Shape &	test,
		DShape &	dtestdx
	)		const

inlineprotected

Shape, test functions & derivs. w.r.t. to global coords. at integration point ipt. Return Jacobian.

Define the shape functions and test functions and derivatives w.r.t. global coordinates and return Jacobian of mapping.

Galerkin: Test functions = shape functions

Definition at line 759 of file gen_axisym_advection_diffusion_elements.h.

Referenced by QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::dshape_and_dtest_eulerian_cons_axisym_adv_diff().

◆ dshape_and_dtest_eulerian_cons_axisym_adv_diff()

template<unsigned NNODE_1D>

double QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::dshape_and_dtest_eulerian_cons_axisym_adv_diff	(	const Vector< double > &	s,
		Shape &	psi,
		DShape &	dpsidx,
		Shape &	test,
		DShape &	dtestdx
	)		const

inlineprotected

Shape, test functions & derivs. w.r.t. to global coords. Return Jacobian.

Define the shape functions and test functions and derivatives w.r.t. global coordinates and return Jacobian of mapping.

Galerkin: Test functions = shape functions

Definition at line 725 of file gen_axisym_advection_diffusion_elements.h.

References QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::dshape_and_dtest_eulerian_at_knot_cons_axisym_adv_diff(), and i.

Referenced by QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::output_fct().

◆ output() [1/4]

template<unsigned NNODE_1D>

void QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::output ( std::ostream & outfile )

inline

Output function: r,z,u.

Definition at line 647 of file gen_axisym_advection_diffusion_elements.h.

References oomph::output().

◆ output() [2/4]

template<unsigned NNODE_1D>

void QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::output	(	std::ostream &	outfile,
		const unsigned &	n_plot
	)

inline

Output function: r,z,u at n_plot^2 plot points.

Definition at line 652 of file gen_axisym_advection_diffusion_elements.h.

References oomph::output().

◆ output() [3/4]

template<unsigned NNODE_1D>

void QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::output ( FILE * file_pt )

inline

C-style output function: r,z,u.

Definition at line 658 of file gen_axisym_advection_diffusion_elements.h.

References oomph::output().

◆ output() [4/4]

template<unsigned NNODE_1D>

void QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::output	(	FILE *	file_pt,
		const unsigned &	n_plot
	)

inline

C-style output function: r,z,u at n_plot^2 plot points.

Definition at line 665 of file gen_axisym_advection_diffusion_elements.h.

References oomph::output().

◆ output_fct() [1/2]

template<unsigned NNODE_1D>

void QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::output_fct	(	std::ostream &	outfile,
		const unsigned &	n_plot,
		FiniteElement::SteadyExactSolutionFctPt	exact_soln_pt
	)

inline

Output function for an exact solution: r,z,u_exact at n_plot^2 plot points.

Definition at line 672 of file gen_axisym_advection_diffusion_elements.h.

References oomph::output_fct().

◆ output_fct() [2/2]

template<unsigned NNODE_1D>

void QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::output_fct	(	std::ostream &	outfile,
		const unsigned &	n_plot,
		const double &	time,
		FiniteElement::UnsteadyExactSolutionFctPt	exact_soln_pt
	)

inline

Output function for a time-dependent exact solution. r,z,u_exact at n_plot^2 plot points (Calls the steady version)

Definition at line 682 of file gen_axisym_advection_diffusion_elements.h.

References oomph::dshape_and_dtest_eulerian_at_knot_cons_axisym_adv_diff(), oomph::dshape_and_dtest_eulerian_cons_axisym_adv_diff(), QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::dshape_and_dtest_eulerian_cons_axisym_adv_diff(), oomph::output_fct(), and s.

◆ required_nvalue()

template<unsigned NNODE_1D>

unsigned QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::required_nvalue ( const unsigned & n ) const

inline

Broken assignment operator.

Required # of `values' (pinned or dofs) at node n

Definition at line 642 of file gen_axisym_advection_diffusion_elements.h.

Member Data Documentation

◆ Initial_Nvalue

template<unsigned NNODE_1D>

const unsigned QGeneralisedAxisymAdvectionDiffusionElement< NNODE_1D >::Initial_Nvalue

staticprivate

Static array of ints to hold number of variables at nodes: Initial_Nvalue[n].

Definition at line 616 of file gen_axisym_advection_diffusion_elements.h.

The documentation for this class was generated from the following file:

gen_axisym_advection_diffusion_elements.h
