#include <fish_mesh.template.h>
Public Member Functions | |
| RefineableFishMesh (TimeStepper *time_stepper_pt=&Mesh::Default_TimeStepper) | |
| Constructor: Pass pointer to timestepper – defaults to (Steady) default timestepper defined in the Mesh base class. More... | |
| RefineableFishMesh (GeomObject *back_pt, TimeStepper *time_stepper_pt=&Mesh::Default_TimeStepper) | |
| Constructor: Pass pointer GeomObject that defines the fish's back and pointer to timestepper (defaults to (Steady) default timestepper defined in Mesh) More... | |
| virtual | ~RefineableFishMesh () |
| Destructor: Empty – all cleanup gets handled in the base classes. More... | |
 Public Member Functions inherited from oomph::FishMesh< ELEMENT > | |
| FishMesh (TimeStepper *time_stepper_pt=&Mesh::Default_TimeStepper) | |
| Constructor: Pass pointer to timestepper (defaults to the (Steady) default timestepper defined in Mesh) More... | |
| FishMesh (GeomObject *back_pt, TimeStepper *time_stepper_pt=&Mesh::Default_TimeStepper) | |
| Constructor: Pass pointer GeomObject that defines the fish's back and pointer to timestepper (defaults to the (Steady) default timestepper defined in Mesh) More... | |
| virtual | ~FishMesh () |
| Destructor: Kill the geom object that represents the fish's back (if necessary) More... | |
| GeomObject *& | fish_back_pt () |
| Access function to geom object that represents the fish's back. More... | |
| FishDomain *& | domain_pt () |
| Access function to FishDomain. More... | |
Protected Member Functions | |
| void | setup_adaptivity () |
| Setup all the information that's required for spatial adaptivity: Set pointers to macro elements and build quadtree forest. (contained in separate function as this functionality is common to both constructors),. More... | |
| Protected Member Functions inherited from oomph::FishMesh< ELEMENT > | |
| void | build_mesh (TimeStepper *time_stepper_pt) |
| Build the mesh, using the geometric object identified by Back_pt. More... | |
Additional Inherited Members | |
| Protected Types inherited from oomph::FishMesh< ELEMENT > | |
| enum | { Lower_body, Upper_body, Lower_fin, Upper_fin } |
| Remesh function ids. More... | |
| Protected Attributes inherited from oomph::FishMesh< ELEMENT > | |
| GeomObject * | Back_pt |
| Pointer to fish back. More... | |
| FishDomain * | Domain_pt |
| Pointer to domain. More... | |
| bool | Must_kill_fish_back |
| Do I need to kill the fish back geom object? More... | |
Detailed Description
template<class ELEMENT>
class oomph::RefineableFishMesh< ELEMENT >
Refineable fish shaped mesh. The geometry is defined by the Domain object FishDomain.
Definition at line 134 of file fish_mesh.template.h.
Constructor & Destructor Documentation
◆ RefineableFishMesh() [1/2]
|
inline |
Constructor: Pass pointer to timestepper – defaults to (Steady) default timestepper defined in the Mesh base class.
Definition at line 144 of file fish_mesh.template.h.
◆ RefineableFishMesh() [2/2]
|
inline |
Constructor: Pass pointer GeomObject that defines the fish's back and pointer to timestepper (defaults to (Steady) default timestepper defined in Mesh)
Definition at line 159 of file fish_mesh.template.h.
◆ ~RefineableFishMesh()
|
inlinevirtual |
Destructor: Empty – all cleanup gets handled in the base classes.
Definition at line 172 of file fish_mesh.template.h.
Member Function Documentation
◆ setup_adaptivity()
|
protected |
Setup all the information that's required for spatial adaptivity: Set pointers to macro elements and build quadtree forest. (contained in separate function as this functionality is common to both constructors),.
Setup all the information that's required for spatial adaptivity: Build quadtree forest.
Definition at line 702 of file fish_mesh.template.cc.
The documentation for this class was generated from the following files:
