Inheritance diagram for oomph::FluidInterfaceElement:

Public Member Functions
	FluidInterfaceElement ()
	Constructor, set the default values of the booleans and pointers (null) More...

virtual double	sigma (const Vector< double > &s_local)
	Virtual function that specifies the non-dimensional surface tension as a function of local position within the element. The default behaviour is a constant surface tension of value 1.0 This function can be overloaded in more specialised elements to incorporate variations in surface tension. More...

void	fill_in_contribution_to_residuals (Vector< double > &residuals)
	Calculate the residuals by calling the generic residual contribution. More...

const double &	ca () const
	The value of the Capillary number. More...

double *&	ca_pt ()
	Pointer to the Capillary number. More...

const double &	st () const
	The value of the Strouhal number. More...

double *&	st_pt ()
	The pointer to the Strouhal number. More...

double	u (const unsigned &j, const unsigned &i)
	Return the i-th velocity component at local node j. More...

double	interpolated_u (const Vector< double > &s, const unsigned &i)
	Calculate the i-th velocity component at the local coordinate s. More...

double	pext () const
	Return the value of the external pressure. More...

void	set_external_pressure_data (Data *external_pressure_data_pt)
	Set the Data that contains the single pressure value that specifies the "external pressure" for the interface/free-surface. Setting this only makes sense if the interface is, in fact, a free surface (well, an interface to another inviscid fluid if you want to be picky). More...

void	set_external_pressure_data (Data *external_pressure_data_pt, const unsigned &index_of_external_pressure_value)
	Set the Data that contains the pressure value that specifies the "external pressure" for the interface/free-surface. Setting this only makes sense if the interface is, in fact, a free surface (well, an interface to another inviscid fluid if you want to be picky). Second argument specifies the index of the pressure value within the Data object. More...

virtual FluidInterfaceBoundingElement *	make_bounding_element (const int &face_index)
	Create a bounding element e.g. to apply a contact angle boundary condition. More...

virtual void	hijack_kinematic_conditions (const Vector< unsigned > &bulk_node_number)=0
	Hijack the kinematic condition at the node numbers passed in the vector. The node numbers correspond to the local numbers of nodes in the associated bulk element. This is required so that contact-angle conditions can be applied by the FluidInterfaceBoundingElements. More...

void	output (std::ostream &outfile)
	Overload the output function. More...

void	output (std::ostream &outfile, const unsigned &n_plot)
	Output function. More...

void	output (FILE *file_pt)
	Overload the C-style output function. More...

void	output (FILE *file_pt, const unsigned &n_plot)
	C-style Output function. More...

Protected Member Functions
virtual int	kinematic_local_eqn (const unsigned &n)=0
	Access function that returns the local equation number for the (scalar) kinematic equation associated with the j-th local node. This must be overloaded by specific interface elements and depends on the method for handing the free-surface deformation. More...

int	pext_local_eqn ()
	Access function for the local equation number that corresponds to the external pressure. More...

virtual void	fill_in_generic_residual_contribution_interface (Vector< double > &residuals, DenseMatrix< double > &jacobian, unsigned flag)
	Helper function to calculate the residuals and (if flag==1) the Jacobian of the equations. This is implemented generically using the surface divergence information that is overloaded in each element i.e. axisymmetric, two- or three-dimensional. More...

virtual double	compute_surface_derivatives (const Shape &psi, const DShape &dpsids, const DenseMatrix< double > &interpolated_t, const Vector< double > &interpolated_x, DShape &dpsidS, DShape &dpsidS_div)=0
	Compute the surface gradient and surface divergence operators given the shape functions, derivatives, tangent vectors and position. All derivatives and tangent vectors should be formed with respect to the local coordinates. More...

virtual void	add_additional_residual_contributions_interface (Vector< double > &residuals, DenseMatrix< double > &jacobian, const unsigned &flag, const Shape &psif, const DShape &dpsifds, const DShape &dpsifdS, const DShape &dpsifdS_div, const Vector< double > &s, const Vector< double > &interpolated_x, const Vector< double > &interpolated_n, const double &W, const double &J)
	Helper function to calculate the additional contributions to the resisuals and Jacobian that arise from specific node update strategies. This is called within the integration loop over the element (for efficiency) and therefore requires a fairly large number of input parameters: More...

Protected Attributes
Vector< unsigned >	U_index_interface
	Nodal index at which the i-th velocity component is stored. More...

int	External_data_number_of_external_pressure
	The Data that contains the external pressure is stored as external Data for the element. Which external Data item is it? (int so it can be initialised to -1, indicating that external pressure hasn't been set). More...

Data *	Pext_data_pt
	Pointer to the Data item that stores the external pressure. More...

unsigned	Index_of_external_pressure_value
	Which of the values in Pext_data_pt stores the external pressure. More...

Private Attributes
double *	Ca_pt
	Pointer to the Capillary number. More...

double *	St_pt
	Pointer to the Strouhal number. More...

Static Private Attributes
static double	Default_Physical_Constant_Value = 1.0
	Default value for physical constants. More...

Friends
class	FluidInterfaceBoundingElement

Detailed Description

Base class establishing common interfaces and functions for all Navier-Stokes-like fluid interface elements. Namely, elements that represent either a free surface or an interface between two fluids that have distinct momentum-like equation for each velocity component.

Definition at line 322 of file interface_elements.h.

Constructor & Destructor Documentation

◆ FluidInterfaceElement()

oomph::FluidInterfaceElement::FluidInterfaceElement ( )

inline

Constructor, set the default values of the booleans and pointers (null)

Definition at line 448 of file interface_elements.h.

Member Function Documentation

◆ add_additional_residual_contributions_interface()

virtual void oomph::FluidInterfaceElement::add_additional_residual_contributions_interface	(	Vector< double > &	residuals,
		DenseMatrix< double > &	jacobian,
		const unsigned &	flag,
		const Shape &	psif,
		const DShape &	dpsifds,
		const DShape &	dpsifdS,
		const DShape &	dpsifdS_div,
		const Vector< double > &	s,
		const Vector< double > &	interpolated_x,
		const Vector< double > &	interpolated_n,
		const double &	W,
		const double &	J
	)

inlineprotectedvirtual

Helper function to calculate the additional contributions to the resisuals and Jacobian that arise from specific node update strategies. This is called within the integration loop over the element (for efficiency) and therefore requires a fairly large number of input parameters:

the velocity shape functions and their derivatives w.r.t. the local coordinates
the surface gradient and divergence of the velocity shape functions
The local and Eulerian coordinates,
the outer unit normal,
the integration weight from the integration scheme
the Jacobian of the mapping between the local and global coordinates along the element. (Note that in the axisymmmetric case this includes the r term)!

Definition at line 430 of file interface_elements.h.

◆ ca()

const double& oomph::FluidInterfaceElement::ca ( ) const

inline

The value of the Capillary number.

Definition at line 475 of file interface_elements.h.

References oomph::FluidInterfaceBoundingElement::Ca_pt.

Referenced by oomph::SurfactantTransportInterfaceElement::add_additional_residual_contributions_interface().

◆ ca_pt()

double*& oomph::FluidInterfaceElement::ca_pt ( )

inline

Pointer to the Capillary number.

Definition at line 494 of file interface_elements.h.

References oomph::FluidInterfaceBoundingElement::Ca_pt.

◆ compute_surface_derivatives()

virtual double oomph::FluidInterfaceElement::compute_surface_derivatives	(	const Shape &	psi,
		const DShape &	dpsids,
		const DenseMatrix< double > &	interpolated_t,
		const Vector< double > &	interpolated_x,
		DShape &	dpsidS,
		DShape &	dpsidS_div
	)

protectedpure virtual

Compute the surface gradient and surface divergence operators given the shape functions, derivatives, tangent vectors and position. All derivatives and tangent vectors should be formed with respect to the local coordinates.

Return the jacobian of the surface, as well as the dpsidS, and dpsidS_div objects.

This is the only function that needs to be overloaded to specify different geometries.

In order to compute the surface gradient of a scalar function one needs only compute the sum over the nodes of dpsidS(l,i) * nodal_value(l,scalar_index) To compute the surface divergence of a vector quantity one computes a sum over nodes and coordinate directions dpsidS_div(l,i) * nodal_value(l,vector_index[i]) In Cartesian cordinates the two surface derivatives are the same, but in Axisymmetric coordinates they are not!

Referenced by oomph::SurfactantTransportInterfaceElement::integrate_c().

◆ fill_in_contribution_to_residuals()

void oomph::FluidInterfaceElement::fill_in_contribution_to_residuals ( Vector< double > & residuals )

inline

Calculate the residuals by calling the generic residual contribution.

Definition at line 465 of file interface_elements.h.

◆ fill_in_generic_residual_contribution_interface()

void oomph::FluidInterfaceElement::fill_in_generic_residual_contribution_interface	(	Vector< double > &	residuals,
		DenseMatrix< double > &	jacobian,
		unsigned	flag
	)

protectedvirtual

Helper function to calculate the residuals and (if flag==1) the Jacobian of the equations. This is implemented generically using the surface divergence information that is overloaded in each element i.e. axisymmetric, two- or three-dimensional.

Calculate the contribution to the residuals from the interface implemented generically with geometric information to be added from the specific elements

Definition at line 474 of file interface_elements.cc.

References oomph::FluidInterfaceBoundingElement::ca(), oomph::FluidInterfaceBoundingElement::kinematic_local_eqn(), and output().

◆ hijack_kinematic_conditions()

virtual void oomph::FluidInterfaceElement::hijack_kinematic_conditions ( const Vector< unsigned > & bulk_node_number )

pure virtual

Hijack the kinematic condition at the node numbers passed in the vector. The node numbers correspond to the local numbers of nodes in the associated bulk element. This is required so that contact-angle conditions can be applied by the FluidInterfaceBoundingElements.

◆ interpolated_u()

double oomph::FluidInterfaceElement::interpolated_u	(	const Vector< double > &	s,
		const unsigned &	i
	)

Calculate the i-th velocity component at the local coordinate s.

Calculate the i-th velocity component at local coordinate s.

Definition at line 449 of file interface_elements.cc.

Referenced by oomph::SurfactantTransportInterfaceElement::add_additional_residual_contributions_interface(), oomph::LineFluidInterfaceBoundingElement::fill_in_generic_residual_contribution_interface_boundary(), and oomph::SurfactantTransportInterfaceElement::output().

◆ kinematic_local_eqn()

virtual int oomph::FluidInterfaceElement::kinematic_local_eqn ( const unsigned & n )

protectedpure virtual

Access function that returns the local equation number for the (scalar) kinematic equation associated with the j-th local node. This must be overloaded by specific interface elements and depends on the method for handing the free-surface deformation.

◆ make_bounding_element()

virtual FluidInterfaceBoundingElement* oomph::FluidInterfaceElement::make_bounding_element ( const int & face_index )

inlinevirtual

Create a bounding element e.g. to apply a contact angle boundary condition.

Definition at line 606 of file interface_elements.h.

◆ output() [1/4]

void oomph::FluidInterfaceElement::output ( std::ostream & outfile )

inline

Overload the output function.

Definition at line 625 of file interface_elements.h.

References oomph::FluidInterfaceBoundingElement::output().

Referenced by fill_in_generic_residual_contribution_interface(), and output().

◆ output() [2/4]

void oomph::FluidInterfaceElement::output	(	std::ostream &	outfile,
		const unsigned &	n_plot
	)

Output function.

Overload the output functions generically.

Definition at line 677 of file interface_elements.cc.

References output().

◆ output() [3/4]

void oomph::FluidInterfaceElement::output ( FILE * file_pt )

inline

Overload the C-style output function.

Definition at line 631 of file interface_elements.h.

References oomph::FluidInterfaceBoundingElement::output().

◆ output() [4/4]

void oomph::FluidInterfaceElement::output	(	FILE *	file_pt,
		const unsigned &	n_plot
	)

C-style Output function.

Overload the output function.

Definition at line 714 of file interface_elements.cc.

◆ pext()

double oomph::FluidInterfaceElement::pext ( ) const

inline

Return the value of the external pressure.

Definition at line 510 of file interface_elements.h.

◆ pext_local_eqn()

int oomph::FluidInterfaceElement::pext_local_eqn ( )

inlineprotected

Access function for the local equation number that corresponds to the external pressure.

Definition at line 364 of file interface_elements.h.

◆ set_external_pressure_data() [1/2]

void oomph::FluidInterfaceElement::set_external_pressure_data ( Data * external_pressure_data_pt )

inline

Set the Data that contains the single pressure value that specifies the "external pressure" for the interface/free-surface. Setting this only makes sense if the interface is, in fact, a free surface (well, an interface to another inviscid fluid if you want to be picky).

Definition at line 530 of file interface_elements.h.

◆ set_external_pressure_data() [2/2]

void oomph::FluidInterfaceElement::set_external_pressure_data	(	Data *	external_pressure_data_pt,
		const unsigned &	index_of_external_pressure_value
	)

inline

Set the Data that contains the pressure value that specifies the "external pressure" for the interface/free-surface. Setting this only makes sense if the interface is, in fact, a free surface (well, an interface to another inviscid fluid if you want to be picky). Second argument specifies the index of the pressure value within the Data object.

Definition at line 569 of file interface_elements.h.

◆ sigma()

virtual double oomph::FluidInterfaceElement::sigma ( const Vector< double > & s_local )

inlinevirtual

Virtual function that specifies the non-dimensional surface tension as a function of local position within the element. The default behaviour is a constant surface tension of value 1.0 This function can be overloaded in more specialised elements to incorporate variations in surface tension.

Reimplemented in oomph::SurfactantTransportInterfaceElement.

Definition at line 462 of file interface_elements.h.

◆ st()

const double& oomph::FluidInterfaceElement::st ( ) const

inline

The value of the Strouhal number.

Definition at line 497 of file interface_elements.h.

◆ st_pt()

double* & oomph::FluidInterfaceElement::st_pt ( )

inline

The pointer to the Strouhal number.

Definition at line 500 of file interface_elements.h.

◆ u()

double oomph::FluidInterfaceElement::u	(	const unsigned &	j,
		const unsigned &	i
	)

inline

Return the i-th velocity component at local node j.

Definition at line 503 of file interface_elements.h.

Referenced by oomph::SurfactantTransportInterfaceElement::output().

Friends And Related Function Documentation

◆ FluidInterfaceBoundingElement

friend class FluidInterfaceBoundingElement

friend

Definition at line 325 of file interface_elements.h.

Member Data Documentation

◆ Ca_pt

double* oomph::FluidInterfaceElement::Ca_pt

private

Pointer to the Capillary number.

Definition at line 330 of file interface_elements.h.

◆ Default_Physical_Constant_Value

double oomph::FluidInterfaceElement::Default_Physical_Constant_Value = 1.0

staticprivate

Default value for physical constants.

Default value for physical constant (static)

Definition at line 336 of file interface_elements.h.

Referenced by oomph::LineFluidInterfaceBoundingElement::fill_in_generic_residual_contribution_interface_boundary().

◆ External_data_number_of_external_pressure

int oomph::FluidInterfaceElement::External_data_number_of_external_pressure

protected

The Data that contains the external pressure is stored as external Data for the element. Which external Data item is it? (int so it can be initialised to -1, indicating that external pressure hasn't been set).

Definition at line 348 of file interface_elements.h.

◆ Index_of_external_pressure_value

unsigned oomph::FluidInterfaceElement::Index_of_external_pressure_value

protected

Which of the values in Pext_data_pt stores the external pressure.

Definition at line 354 of file interface_elements.h.

◆ Pext_data_pt

Data* oomph::FluidInterfaceElement::Pext_data_pt

protected

Pointer to the Data item that stores the external pressure.

Definition at line 351 of file interface_elements.h.

◆ St_pt

double* oomph::FluidInterfaceElement::St_pt

private

Pointer to the Strouhal number.

Definition at line 333 of file interface_elements.h.

◆ U_index_interface

Vector<unsigned> oomph::FluidInterfaceElement::U_index_interface

protected

Nodal index at which the i-th velocity component is stored.

Definition at line 342 of file interface_elements.h.

Referenced by oomph::SurfactantTransportInterfaceElement::add_additional_residual_contributions_interface(), and oomph::SurfactantTransportInterfaceElement::output().

The documentation for this class was generated from the following files:

Public Member Functions

Protected Member Functions

Protected Attributes

Private Attributes

Static Private Attributes

Friends

Detailed Description

Constructor & Destructor Documentation

◆ FluidInterfaceElement()

Member Function Documentation

◆ add_additional_residual_contributions_interface()

◆ ca()

◆ ca_pt()

◆ compute_surface_derivatives()

◆ fill_in_contribution_to_residuals()

◆ fill_in_generic_residual_contribution_interface()

◆ hijack_kinematic_conditions()

◆ interpolated_u()

◆ kinematic_local_eqn()

◆ make_bounding_element()

◆ output() [1/4]

◆ output() [2/4]

◆ output() [3/4]

◆ output() [4/4]

◆ pext()

◆ pext_local_eqn()

◆ set_external_pressure_data() [1/2]

◆ set_external_pressure_data() [2/2]

◆ sigma()

◆ st()

◆ st_pt()

◆ u()

Friends And Related Function Documentation

◆ FluidInterfaceBoundingElement

Member Data Documentation

◆ Ca_pt

◆ Default_Physical_Constant_Value

◆ External_data_number_of_external_pressure

◆ Index_of_external_pressure_value

◆ Pext_data_pt

◆ St_pt

◆ U_index_interface
